Silent Angel F1 Power Supply
To fulfill all Hi-Fi requirements on stable power source and multiple output connector type, Silent Angel perfectly add multiple technologies into F1, which includes: high-efficiency toroidal transformer, advanced fully symmetric circuit design, low noise MOSFET in parallel and EMI filter.
It is not only a power supply, but also a guardian for the music journey. Compared with cheaper power supply, F1 has a more stable electricity input to ensure the consistency and integrity of the music enjoyment. Reference to running test, ONE F1 can easily provide continuous and pure power to TWO N8 simultaneously. The toroidal design approximately halves the occupied space and the weight of transformer comparing with the laminated design at the same degree. The improvement of efficiency is more obvious as well. The core permeability of toroidal design is higher than the laminated, which conduce to the electrical efficiency of transformer trend better consequently. In addition, the energy-saving superiority of toroidal design is that the no-load current is merely 10% comparing with the laminated.
|Dimensions||155mm (W) x 115mm (D) x 58mm (H)|
|Input||230VAC or 115VAC 50/60Hz (with voltage selector)|
|Output Connectors||DC PLUG *2, USB Type-A Female Connectos *2|
|LED indicators||Status LED *2, Over-Temperature-Protection LED *2|
