Acelec Model One Speakers
2 In stock
Audio Art Cable USA
Model One is possibly the most transparent conventional loudspeaker available today. Over the last two years, intensive research has been dedicated to exploring new methodologies and materials. These are now incorporated in our latest product range. Model One is a premium loudspeaker, offering absolute performance from the clean lines of its compact cabinet.
Silver finish available by special order. 7-10 days to deliver. Contact us for details.
The shape has been designed to deliver detailed and powerful sound reproduction - usually only associated with much larger loudspeakers. The technical criteria were quite simple. Extreme stiffness using bituminized aluminium and internal damping of the cabinet to avoid any ringing effects. As a result, this approach avoids any time smearing, particularly with regard to fast and powerful transients. Placement within a normal living environment was also a design goal, so that performance would not be hampered, for example, by close proximity to room boundaries e.g. walls and corners. Furthermore, the design had to behave efficiently and at the same time act as a simple load for a wide range of Amplifiers - encompassing both delicate Tubes, as well as powerful Solid-State powerhouses
System Format: 2-way
Housing: 15 mm bituminized aluminum
Bass Alignment: Low Q alignment Vented port system.
Frequency Response (-6 dB): 45 Hz – 35 kHz , Max. deviation ± 2.5 dB
Sensitivity (1W@1M): 84 dB
Nominal Impedance: 8 ohms
Minimum Impedance: 5 ohms at 375 Hz
Maximum SPL: 110 dBA (Pair)
Power Handling (RMS): 120 W
Recommended Amplifier Requirements: 25 – 100 W
Crossover Frequency: 1.8 kHz
Drive Unit Complement: 15cm bass / mid transducer, 18 mmAir Motion Transformer
Cabinet Dimensions (H x W x D): 285 x 195 x 300 mm
Finish: Silver or black finish
Weight: 17 kg
