The Shanling EC Zero T MAX is a premium portable CD player featuring a custom 24-bit R2R DAC, dual JAN6418 vacuum tubes, and a powerful balanced headphone amplifier. New MAX edition builds upon the acclaimed sound of Shanling EC Zero T, implementing the latest Shanling expertise in R2R DACs and following end-user feedback with an improved headphone amplifier.
Pairs well with
25% off any AAC cable with the purchase of a component or speaker (automatically discounts in cart; excludes upgrades and accessories)
30-day returns - see return policy
If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, within 24 hours on weekdays.
-
Shipping Information
Cables: FREE 2-4-day domestic shipping.
Components: FREE domestic shipping on most of our component and speaker products. -
Customer Support
Our expert audio enthusiast will guide you through this musical journey. Rob is available to answer your questions so that you can join the countless high-end audio systems satisfied clients.
-
FAQ’s
Audio Art Cable strategically assembles cost effective Hi-fi systems with overachieving performance. The cable mission is simple, deliver factory direct to consumers at an exceptional price. Components are curated from the best manufacturers around the world with a value that cannot be surpassed.
-
Contact Us
(619) 255-6451
rob@audioartcable.com
or click the chat icon
Product details
Description
The upgraded amplifier circuit was designed around AD8397, delivering increased output without any need for external power and achieving significantly reduced output impedance. Making MAX a better match for both the demanding full-size headphones and the most advanced in-ear earphones, all while preserving the rich and warm sound of the EC Zero T.
MAX comes with the same R2R module as the original EC Zero T, featuring 24-bit architecture with 192 high-precision 0.1% resistors. But following the development of our PRO R2R DAC from SCD3.3 and SCD1.3R, we implemented a range of DAC circuit and power optimizations into the MAX, now offering an even wider and deeper soundstage, while enjoying a bit of increased transparency across midrange and treble regions.
Thanks to the upgraded amplifier circuit, EC Zero T MAX provides up to 1300mW @ 32Ω Balanced / 361mW @ 32Ω Single-Ended output power while running directly on its battery and without any need for an external power supply.
MAX edition comes in a smooth Titanium grey finish, featuring a new intricate pattern on the CD cover and adding a few hidden visual elements to its surfaces.
Specifications
- Color: Titanium
- Chassis: CNC-machined aluminum
- CD Cover: Tempered glass with MAX-pattern detailing
- DAC Architecture: Shanling in-house developed 24-bit R2R DAC
- R2R Network: 192 high-precision 0.1% resistors
- Digital Filtering: Selectable OS and NOS modes
- Vacuum Tubes: 2 × JAN6418
- Output Modes: Switchable tube and transistor analog signal paths
- Headphone Amplifier: High-power AD8397-based amplifier circuit
- Display: 1.68-inch LCD
- Controls: Dedicated physical playback buttons, button lock, and sliding volume control
- Volume Control: Yes
- Balanced Output: Yes
- Single-Ended Output: Yes
- CD Mechanism: Custom CD drive with active magnetic clamp
- Gapless CD Playback: Supported
- CD Ripping: Direct ripping to USB drive at 1× speed
- USB Drive Requirement for CD Ripping: FAT32 format
- USB DAC Support: PCM up to 768 kHz / 32-bit and DSD512
- Bluetooth: Bluetooth 5.3 transmitter mode
- Bluetooth Codecs: aptX Adaptive, aptX, SBC
- Digital Output: 3.5 mm coaxial and optical SPDIF
- Headphone Outputs: 3.5 mm single-ended and 4.4 mm balanced
- Dedicated Line Outputs: 3.5 mm single-ended and 4.4 mm balanced
- 3.5 mm Headphone Output, Transistor Mode: 37 mW low gain / 361 mW high gain at 32 Ω
- 3.5 mm Headphone Output, Tube Mode: 39 mW low gain / 361 mW high gain at 32 Ω
- 3.5 mm Output Impedance: 0.4 Ω
- 3.5 mm Dynamic Range: 115 dB
- 3.5 mm Signal-to-Noise Ratio: 115 dB
- 3.5 mm THD+N, Transistor Mode: 0.02%
- 3.5 mm THD+N, Tube Mode: 1%
- 4.4 mm Headphone Output, Transistor Mode: 211 mW low gain / 1300 mW high gain at 32 Ω
- 4.4 mm Headphone Output, Tube Mode: 151 mW low gain / 1162 mW high gain at 32 Ω
- 4.4 mm Output Impedance: 0.7 Ω
- 4.4 mm Dynamic Range: 116 dB
- 4.4 mm Signal-to-Noise Ratio: 116 dB
- 4.4 mm THD+N, Transistor Mode: 0.02%
- 4.4 mm THD+N, Tube Mode: 1%
- 3.5 mm Line Output: 2.12 Vrms in transistor mode / 1.8 Vrms in tube mode
- 4.4 mm Line Output: 4.2 Vrms in transistor mode / 3.6 Vrms in tube mode
- Frequency Response, CD Playback: 20 Hz–20 kHz
- Frequency Response, USB DAC and Line Output: 20 Hz–40 kHz
- Battery: Built-in 5500 mAh rechargeable battery
- 3.5 mm Playback Time: Up to 8 hours
- 4.4 mm Playback Time: Approximately 7.5 hours
- Bluetooth Transmitter Battery Life: Up to 20 hours
- External Power: USB-C, 5 V / 2 A
- External Power Mode: Can operate from USB-C power while reducing direct operating load on the internal battery
- Dimensions: 158 × 150 × 28 mm
- Device Weight: Approximately 669 g
- Listed Shipping/Piece Weight: 1.1 kg per piece
- Included CD Player: 1 × Shanling EC Zero T MAX
- Included Cable: 1 × factory USB cable
- Documentation: User guide and warranty documentation
