Electrocompaniet ECM 1 MKII High End DAC & Music Streamer

In stock

In stock

Audio Art Cable USA

ELECTROCOMPANIET-STREAMER-ECM-1-MKII

$5,700.00

THE FUTURE OF LISTENING AND THE HERITAGE OF ELECTROCOMPANIET



The new ECM 1 MKII is a DAC and music streamer. With the brand new, in-house developed streaming software and app, it plays lossless, DSD and high-resolution digital content in a way that really makes you want to dig deeper into all the delightful music out there.  The ECM 1 MKII has updated technical and sonic enhancements, as well as new mechanics and a design in line with the new MKII versions of their products.



EC Software Engine



The ECM 1 MKII uses the same app and interface as our EC Living line, enabling you to play all your music on all of the units.
You don´t have to choose between high-end and multi-room, or flexibility and audio quality.  It's all there.



Even better Streaming



ECM 1 MKII's streamer is powerful, flexible and easy to use. It plays directly from Tidal, Spotify and Qobuz and can be fed through AirPlay, DLNA or Bluetooth.



Reference DAC



Two state of the art, natural sounding Cirrus Logic converters handle one channel each with 192 kHz at 24 bits, along with a completely symmetrical analog output stage.


The Future of listening and the heritage of Electrocompaniet.

Improved Design- The ECM 1 MKII has updated technical and sonic enhancements, as well as new mechanics and design in line with the new MKII versions of our products.

EC Software Engine- The ECM 1 MKII uses the same app and interface as our EC Living line, enabling you to play all your music on all of the units.
You don´t have to choose between high-end and multi-room, or flexibility and audio quality.

Better Streaming- The streamer is very powerful, flexible and easy to use. It plays directly from Tidal, Spotify and Qobuz and can be fed through AirPlay, DLNA or Bluetooth.

DAC- The two Cirrus Logic converters handles one channel each with 192 kHz at 24 bits.

Reference Analog Stage- The Analog output stage is completely symmetrical
Technical Data
  All measurements are made at 120V / 240V  //50Hz / 60Hz
No. of channels 2
Output Impedance 300 Ohms
Noise floor (20 - 20 kHz) < -145 dB
Frequency response 0.5 - 48 kHz
THD+N < 0,0005 %
Upsampling rate 192 kHz, 24 bit
Digital/Analog conversion 192 kHz, 24 bit

Input sampling rate:
2 x SPDIF Coax  192 kHz, 24 bit
2 x SPDIF TOSLink  192 kHz, 24 bit

Network connection: Wi-Fi or LAN

Internal drive:

Docking, self installation. 3.5"/2.5" - unlimited capacity.


Supported audio formats: All popular formats including: WAV/WAVE, MP3, AAC+, Vorbis, ALAC, FLAC, APE, AIFF, WMA, up to 192kHZ/24bit, DSD, up to DSD 128 (5.6 MHz)

Supported control interfaces: DLNA, UPnP, Android and iOS remote
Internal storage: docking, self installation


Streaming services:

• AirPlay 2 ®
• Spotify ® Connect
• Qobuz ®
 Plays with Audirvāna
• TIDAL ® Connect
• Roon Ready
• DLNA
• Internet Radio
• Bluetooth streaming from any Bluetooth enabled device


Power consumption
(no load or signal)
50 W
 standby  0.5 W

Dimensions

Width 470 mm / 18.5 inches
Depth 381 mm / 14.99 inches
Height 80 mm / 3.14 inches
Weight

8.3 kg. / 18 lbs.

*(without internal drive)

*The manufacturer reserves the right to alter these

specifications without further notice.
