Electrocompaniet ECP 2 MKII Phono Stage
In stock
With renewed international enthusiasm for the vinyl format, a world-class phono preamplifier or RIAA stage is more important in a reference analog setup than ever before. Electrocompaniet's ECP2-MKII has become a new favorite of reviewers and enthusiasts alike. A true benchmark product in its price bracket, much like other EC components.
ECP2-MKII incorporates only state-of-the-art instrumentation, operational amplifiers (op-amps) along with the highest quality discrete components in the signal path. Of course it is all DC coupled.
ECP2-MKII introduces an all new chassis and front plate design, in line with other products in Electrocompaniet's Classic Line. It will make your vinyl records sing like no other phono preamplifier we know of, and it seems the industry agrees with us.
| Phono section | |
| Gain @ 1 kHz RCA | Adjustable 39,8 – 71,4 dB |
| Gain @ 1 kHz XLR | Adjustable 45,8 – 76,4 dB |
| Resistance loading (RL) | Adjustable 10 Ω – 47 kΩ |
| Capacitive loading (CL) | Adjustable 0 – 350 pF |
| Maximum output level: | 17.5 V rms (+ 25 dB V) |
| Overload margin | > 31 dB @ 1 kHz |
| Output impedance | 100 Ω single-ended, 200 Ω balanced |
| Frequency response | 20 – 20 kHz +/- 0.2 dB |
| RIAA Correction Accuracy | ± 0,1 dB |
| Subsonic filter | -3dB @ 11 Hz, 24 dB/octave |
| Channel separation | > 85 dB, 20 – 20 kHz |
| THD + Noise | < 0.003 % @ 1 kHz |
| S/N-R | 96 dB, 1 kHz, A-weighted, ref. 10 dB V output |
| S/N-R | 91 dB, 1 kHz, A-weighted, ref. 5 mV input |
| S/N-R | 67.4 dB, 1 kHz, A-weighted, ref. 500 μV input |
| Dimensions | |
| Width | 470 mm / 18.5 inches |
| Depth | 373 mm / 14.6 inches |
| Height | 78 mm / 3 inches |
| Weight |
9 kg. / 19.8 lbs. |
